Gear Case Brush Cutter Frame Work Gearbox

RG series gearboxes are widely used in lawn mower. 4200006 gearbox is used for lawn mower transmission. Our gearbox have exported to America, Canada, Australia,Thailand and so on. Agriculture Gearbox which is made with excellent quality of raw materials. These agriculture gearboxes are available in different design and size as customer’s requirements.

Send Inquiry Chat Now

Product Details

1.Product Details

Model no.	4200006
Material	HT250 for housing, 20CrMnTi for gear shaft.
Power	30HP
Ratio	1:1.93 1:1.71 1:1.46
Input Speed	540rpm
Gearing Arrangement	Bevel / Miter

2.Related Products

Related Products

3.Gearbox Manufacturer

GTM specilizes in gearbox customization what including housing and gearing design in light of clients’specifications. We can provide 2D or 3D drawings to customers for reference.

The testing of each production processes as the below:

1.Development testing: Commonly conducted on materials and gear modules, this is useful for determining the feasibility of the design.

2.Sample testing: Sample will be used to provide testing ground with same dimensions and functionalities as the final product.

3.Proof testing: To check any potential issues in sample

4.Acceptance testing: Depending on the criticality of failures, tests may be conducted on initial production units and/or sampling, or every single unit produced.
